Corna Support Catch for Bi-Fold Corner Unit Top Mount

$5.50 (ex GST)

Features: Support Catch – TOP MOUNTING

  1. Catch for three door extended corner units.
  2. Excellent shelf mounted catch for removing bowing and twisting from tall doors
  3. 3 in 1 fitting
SKU: 472.0455 Category:

Features:

Support Catch – TOP MOUNTING

  1. Catch for three door extended corner units.
  2. Excellent shelf mounted catch for removing bowing and twisting from tall doors
  3. 3 in 1 fitting
  4. Catch / Aligner / Protector
  5. Stops Dropping
  6. Stops Scratching
  7. Stops Edge Damage
  8. Smooth Action with strong pull-in from 6mm
  9. Necessary on all bi-fold corner units, particularly when using self closing hinges to connect the bi-folds.
  10. Smooth Action





The catch keeper has a 5mm/ 7/32” diameter pin which locates into a system 32 hole directly behind the location of door handle but towards the top of the door on overhead cupboards.

CODE DESCRIPTION
472.0455 Side Mount Support Catch
